formula s 840p Band saw
Starting from 拢7,898.00
(Price does not include VAT and delivery)
S 840P Industrial Series Bandsaws
The Industrial Series of Bandsaws by formula come with even heavier features and larger motors. These machines are all 3-phase and are meant for heavy duty resaw and are even used in non-wood applications in the advanced materials industries.聽
Solidity and sturdiness
Very thick, cast iron wheels, as well as the worktable, running on sealed for life ball bearings.
Safety first
Total safety machining with telescopic protections with rackwork to the blade.
Perfect results
A perfect cut result is assured by the top and bottom high precision blade guides. Practical machines suitable also to perform straight and tilted cuts on wood, plastic and aluminum.
聽
- Cast-iron squaring fence for maximum stability and cutting repeatability
- Rack and pinion lifting system of the guide unit for a fast and safe setup
- Saw blade tensioning indicator that guarantees immediate and continuous control of the value
- Cast-iron work table with lapped surface for maximum smoothness of the piece
- Full disc cast iron wheels to keep the blade speed constant during machining
- Top and bottom blade guide with ball bearings to minimize lateral movements of the blade and therefore increase the precision of the cut
- Cleaning brush on bottom wheel to reduce the wheel wear
- Fence for angular cuttings
聽
| TECHNICAL FEATURES | ||
| Worktable dimensions | mm | 800 x 1160 |
| Cast iron saw wheels diam. | mm | 840 |
| Saw wheels width | mm | 45 |
| Max. cutting height (inches) | mm | 540 (21�) |
| Max. cutting width | mm | 820 |
| Worktable tilting (CE) | 0° ÷ 45° (20°) | |
| Longueur max. lame | mm | 6110 |
| Standard three-phase motor S1 400V 50Hz | 5,5kW 7,5hp | |
| Standard three-phase motor S1 220V 60Hz | 6,7kW 9hp | |
| Exhaust outlet diameter | mm | N. 2 x 140 |
